Dake Industrial Bandsaw Model V-26E
Free Shipping
Enjoy Free Shipping on Most Products in Store!
No Sales Tax
No Sales Tax on Your Order Except WY*
Why Shop With Us?
- Authorized Retailer for Dake
- Lowest Prices Online
- No Sales Tax (Excluding WY Residents)
- Speak with an Expert Today: 307-222-6334
26" Throat
This heavy-duty vertical bandsaw is designed for large production pieces. A 26″ capacity, power feed table, and variable speeds offer cutting capabilities for many applications. Additional features include a digital tachometer, speed and pitch selector, rip fence, miter gauge, and 4 cutting modes. Complete with a built-in welder/grinder/cutter this saw is sure to get the job done.
*440V model requires step-down transformer for operation (part number: 300674) Sold Separately
Features
- Variable Speeds with 50 – 415 feet per minute in low range and 550 – 5,000 feet per minute in the high range
- Electronic Power Fed Table. Torque motor driven with rack and pinion
- Heavy cast table with chip clearance grooves and back stop bar
- Low voltage controls, main power lock out switch and door limit switches
- Rip Fence, miter gauge, circle cutting attachment
- Built in blade welder with grinder and shear to easily fix broken blades
- Blade speed / pitch selector guide and digital tachometer
- Work light comes standard for increased visibility
Model Options
- 440V External Transformer
- 77178 – Mist system
Standard Equipment
- Heavy Duty Frame
- Rip Fence
- Work Light
- Blade Welder / Grinder / Shear
- Speed Indicator (Digital Readout)
- Blade Tension Indicator
- Digital Tachometer
- Chip Blower & Blade Brush
- 1 Standard Blade
| Model Number | V-26 | |
|---|---|---|
| Part Number | 987032-2 | |
| Horsepower (HP) | 3 | |
| Voltage | 220V | |
| Blade Width (in) | 1/4 - 1 | |
| Blade Length (in) | 184-1/4 | |
| Blade Speed (fpm) | ||
| Worktable Travel Distance (in) | 12 | |
| Band Wheels Number | 2 | |
| Band Wheels Size (in) | 26-1/4 | |
| Throat Size (Band To Column) (in) | 26 | |
| Maximum Work Height (in) | 13 | |
| Work Table Dimensions (in) | 23-1/2 x 27-1/2 | |
| Worktable Tilt | 45° R / 10°L | |
| Worktable Height (in) | 39-3/8 | |
| Machine Height (in) | 84 | |
| Machine Floor Space (in) | 51 x 32 | |
| Weight (lbs) | 1540 | |
